Coil Winding Machine
Through using a coil winding machine it allows one to make an electromagnetic coil that can be used in a variety of different ways. Some of these can be used for relays or resistors whilst other coils can be use as stator, rotor or transformer coils within electric motors or generators. In fact the way in which these types of coils can be used is pretty extensive.
So exactly what does a coil winding machine do?
This machine will take a wire made either from copper or aluminum that it then winds around a core and in some cases it may be air which it is wound around. As a result of this you will find that these types of coils are known as air wound ones. However, the kinds that most of us tend to see are the ones that are wound around a reel.
However, as well as these machines winding the wire around the core during this process other elements can be added such as terminals plus some may be coated with a material to provide them with insulation. Along with the covering being heated or baked on to the wire that has been coiled in some cases it can be vacuum impregnated into it and this will help to ensure that the energy passing through it is conducted far better.
Although you can actually purchase these machines for yourself there are a number of companies that can carry out the task for you. If you do choose to use the services of such companies then it is best to look for those that do perfect layer winding (orthocyclic coil winding) as this helps to make much more compact coils for you to then use.
As you will soon discover when it comes to using these types of coils that they have the ability to conduct heat through them far better. Plus what you will also find that these types of coils have the ability to distribute electric field strength through them far more easily. So of course this means that the equipment in which they are installed will then run more efficiently and effectively.
Another advantage to using a coil winding machine where it creates an orthocyclic coil is that the size of them can be reduced. As a result of this there is far less chance of them burning out when high amounts of voltage pass through them. So of course this again means that they are more than capable of being used in a variety of different situations and will last for considerably longer.
There are many types of coil winding machines out there. First, there are coil winders that are meant for light work or uniquely small jobs. You can buy a hand operated one. Others have a winding drive or torque winder, which can be controlled by a foot pedal. High speed winding benches are made to give you both durable construction and compact work spaces. They are used in the production of trigger coils, solenoid coils, mult-section coils, RF/IF coils, and other complex coils. They may be small, but are quite fast, reaching speeds of up to 9000 RPM. Some more sophisticated models can be operated by a digital touch panel, and can be pre programmed with saved settings. Many of these feature a solid bench for safe working, and cabinets for easy storage of 200 to 250 pounds.
Medium duty coil winding machines are slightly more powerful and durable, to take on higher production needs. Many of them are powered by an AC Flux Vector Drive, designed to give the user a larger speed range and better pulling strength. Some of them are still driven by foot pedals, but more are driven by potentiometers. These are versatile machines that can wind varying types of wire like shaped and round wires. Some even have an instant reverse function. Consider getting a medium duty machine if you plan or find yourself winding up to 1000 pounds.
If you need to wind large amounts, 8000 pounds for example, you surely need a heavy duty coil winding machine. These are the most versatile machines, as they can wind many types and sizes of wire. When you are winding large amounts, it is of utmost importance that you have precision and accuracy, so the majority of these are operated using an LCD touchscreen. This allows the operator to control torque and speed better. The operator can then save settings so he can recall a specific winding program if the need ever arises in the future.
Today the purchasing of a coil winding machine has become a great deal easier because of the internet. Previously the purchase of such equipment would have to be arranged through only a few companies. However, today there are numerous sites where such equipment can be purchased. But you still need to be wary before you do purchase anything through an online company.
Below we take a look at just some of the things that you need to take into consideration when purchasing this kind of product online. Plus we also take a look at what the advantages are of buying a coil winding machine online.
Purchase Considerations
1. You must look carefully at how long the business selling the product has been established for. If they do not include such information on their website then email them requesting the information you are after. A great way of determining if the seller is genuine or not in the USA is by contacting the BBB (Better Business Bureau). They will provide you with details of any companies that have registered with them.
2. When you are looking at purchasing any kind of equipment including a coil winding machine online look to see what contact information the company selling the product provides. Generally the ones that you can trust are those that not only provide you with an email address but also a conventional mailing address along with a telephone number. If these are not provided and they are unwilling to provide such information then look elsewhere to purchase your goods from.
So just what are the advantages to be gained from purchasing such equipment online?
1. What you may well find by purchasing the product you want online rather than from a local store is that the price charged is somewhat less. This is because the online retailer is not faced with the same kinds of overheads that a traditional bricks and mortar retailer is faced with. In many cases you may find that the online retailer acts as an intermediary for the manufacturer of the coil winding machine you are after so they will then send the order to them for the product to then be shipped to you.
However look closely at the prices for shipping such products before ordering. You may well find that the cost of shipping results in the product costing the same if you purchased it locally and this retailer may then deliver it to you free of charge.
2. By ordering online the product you have purchased will be directly shipped to where you work or reside. So of course this means that you don’t have to concern yourself with loading or unloading it as the delivery company will do this work for you. It is simply a case of you then unpacking it and setting it up to run.
However, you may need to make sure that if the machine needs to power to provide energy that the power supply is able to cope with the amount it will need. If not this can lead to a number of bigger problems for you in the future.
Above we have looked at not only how a coil winding machine works but what to look for whether purchasing yours locally online. Certainly when it comes to investing in any equipment like this you should spend a little time learning everything you can about what is available before finally deciding on which one to purchase. By knowing as much as you can about each type will help to ensure that you purchase the one that is going to meet your particular needs the best.
